Motorola SLR 8000 – Digital Repeater Motorola SLR 8000 adalah repeater digital untuk menyediakan komunikasi dua arah berbasis suara dan data dengan performa optimal. Dilengkapi fitur canggih, seperti: analog/digital hybrid, trunking, dan jaringan IP, koneksi repeater ini stabil dan luas. Fitur-Fitur Motorola SLR 8000 Minimalis dan Power Output Besar SLR 8000 hanya setinggi 2U, tetapi dapat beroperasi secara terus-menerus hingga 100 watt dengan sensitivitas tinggi. Serbaguna Repeater Motorola ini menggabungkan fungsi komunikasi dua arah terbaik dengan integrasi suara dan data yang mulus. Repeater ini hadir dengan fitur-fitur canggih yang mudah digunakan serta kapasitas yang ditingkatkan untuk memenuhi berbagai kebutuhan. Dapat Dikembangkan Baik anda memerlukan sistem konvensional di satu lokasi, konektivitas luas melalui IP Site Connect atau kapabilitas trunking yang kuat, SLR 8000 dapat mendukung semuanya. Selain itu, repeater ini juga dapat digunakan sebagai repeater analog atau sebagai repeater campuran analog/digital saat dalam proses migrasi. Spesifikasi Motorola SLR 8000 GENERAL VHF UHF 800/900 Frequency Range 136 – 174 MHz 400 – 470 MHz 800 RX: 806 – 825 MHz TX: 851 – 870 MHz 900 RX: 896 – 902 MHz TX: 935 – 941 MHz Channel Spacing 25*/ 12.5 kHz 12.5 / 20 kHz / 30 kHz Channel Step Size 5 Hz Frequency Stability / – 0.5 PPM / – 0.1 PPM Channel Capacity 64 RF Output Power 1 – 100W Dimensions (H x W x D) 3.5 x 19 x 17.25 in (89 x 483 x 438 mm) Weight 31 lbs (14.1 kg) Input Voltage (AC) 100 – 240 Vac, 47 – 63 Hz Current (standby), 110/240 V 0.25 / 0.3 A 0.27 / 0.31 A Current (transmitting at 100 W), 110/240 V 2.1 / 1.1 A (typical) 2.0 / 1.1 A (typical) 2.8 / 1.3 A (typical) Input Voltage (DC) 12 V (11.0 – 15.5 V) / 24 V (21.6 – 32.0 V) Current (standby), 24 V 0.5 A 0.6 A Current (transmitting at 100 W), 24 V 8.6 A (typical) 8.2 A (typical) 12 A Input Power Modes AC only, DC only, AC with Battery Revert Operating Temperature Range -22 to 140 °F (-30 to 60 °C) Humidity RH of 95%, Non-condensing at 50 °C (122 °F) Max Duty Cycle 100% Digital Vocoder Type AMBE 2™ Battery Charger Capacity (12 / 24 V) 5 A Connectivity, front panel USB B Receptacle, Microphone (RJ45), Speaker (integrated) Connectivity, rear panel Tx (N female), Rx (BNC female), USB A Receptacle, 2x Ethernet, DB25 Accessory Connector, External Reference (BNC Female) External Reference 5 / 10 MHz (Auto-detect) Supported System Types Digital Conventional, IP Site Connect, Capacity Plus, Capacity Max, Connect Plus Analog Conventional, Analog Conventional Voting, MPT 1327 Audio Types Input: Balanced (600 ohms and Country-specific Impedances), Unbalanced (1000 ohms), Microphone Accessory Port. Output: Balanced (600 ohms and Country-specific Impedances), Unbalanced (600 ohms), Integrated Speaker. Audio Levels Input: Balanced: 10 to -30 dBm, Unbalanced: Adjustable, 80 mV rms nominal for 60% RSD. Output: Balanced: 7 to -30 dBm, Unbalanced: Adjustable, 330 mV rms nominal @ 60% RSD. FCC Emission Designators 11K0F3E, 16K0F3E, 7K60FXD, 7K60F7D, 7K60FXE, 7K60F7E, 7K60F7W 11K0F3E, 16K0F3E, 7K60FXD, 7K60F7D, 7K60FXE, 7K60F7E, 7K60F7W, 21K7D7E, 21K7D7D, 21K7D7W FCC Type Acceptance ABZ99FT3095B ABZ99FT4098B ABZ99FT5101B IC Description 109AB-99FT3095B 109AB-99FT4098B 109AB-99FT5101B RECEIVER VHF UHF 800/900 Frequency Range 136 – 174 MHz 400 – 470 MHz 806 – 825 MHz 896 – 902 MHz Sensitivity, 12dB SINAD 0.3 uV (0.22 uV typical) 0.28 uV (0.18 uV typical) Sensitivity, 5% BER 0.25 uV (0.18 uV typical) 0.28 uV (0.18 uV typical) Selectivity (TIA603E), 25* / 12.5 kHz 83 / 52 dB 78/52 dB 78/52 dB Selectivity (TIA603), 25* / 12.5 kHz 83 / 75dB 80/75dB 80/75 dB Intermodulation Rejection (TIA603E/ETSI) 85 / 73 dB (87 / 78 dB typical) 85/73 dB (88 / 79 dB typical) Spurious Rejection (TIA603E/ETSI) 85 / 75 dB (95 / 90 dB typical) 90/75 dB (105 / 90 dB typical) Audio Distortion < 3% (<1.5% typical) Hum and Noise, 25* / 12.5 kHz -50 / -45 dB (-56 / -52 dB typical) Blocking > 110 dB (113 dB typical) TRANSMITTER VHF UHF 800/900 Frequency Range 136 – 174 MHz 400 – 470 MHz 851 – 870 MHz 935 – 941 MHz RF Output Power DC (24 V) or AC 1 – 100 W DC (12 V) 1 – 50 W Max Duty Cycle 100% Intermodulation Attenuation 55 dB Adjacent Channel Power (TIA603E), 25*/ 12.5 kHz 75 / 60 dB Adjacent Channel Power (ETSI), 25* / 12.5 kHz 75 / 60 dB (78 / 62 dB typical) 70 dB / 63 dB (82 / 76 dB typical) Conducted Spurious Emissions -36dBm Audio Response TIA603D Audio Distortion < 3% (<1% typical) Hum and Noise, 25*/ 12.5 kHz -50 / -45 dB (-55 / -52 dB typical) Rated System Deviation, 25* /12.5 kHz ±5.0 / ±2.5 kHz
