Combines a rope grab, pulley, and becket in a compact device for hauling & ascending. Incorporates a force-limiting V-groove Cam designed to provide overload protection. Installs quickly on tensioned and un-tensioned lines, no need for knots or hitches. Opens one-handed and gives simultaneous access to components for rapid rigging. Builds efficient M/A systems and smoothly progresses from a 3:1 to a 5:1 M/A. Releases and resets easily, even after high loading, making it ideal for rescues. Travels down rope in vertical systems, resetting and maximizing the haul field. Allows installation of the Soft Shackle accessory loop for remote resets and device stowage. Provides an integrated becket for M/A components, lanyards, and foot loops. Works well in combination with piggy back systems and additional CAPTOs. Replaces multiple devices in one, streamlining training and operations. Components Multi-functional rope grab with a force-limiting V-groove Cam High-efficiency, 44.5 mm (1.75 in) diameter sheave pulley Integrated becket independent from rope loading / unloading Moving sideplate with double-action release button Hollow cam axle for Soft Shackle accessory loop accessory loop installation (3.9 mm diameter) Ridged Cam Grip for one-handed device positioning Technical Specifications 11 mm (Grey)13 mm (Red)Rope Compatibility 10.5 – 11 mm12.5 – 13 mm3 Sigma MBS36 kN (pulley)36 kN (pulley)Weight513 g508 gDimensions5.92 x 2.75 x 1.23 in5.92 x 2.75 x 1.23 in certifications 11 mm (Grey)13 mm (Red)NFPA G (rope grab w/ 10.5-11 mm rope)NFPA G (rope grab w/ 10.5-11 mm rope)NFPA G (pulley)NFPA G (pulley)EN 12841:2006/BEN 567:2013EN 12278:2007 videos
