Wiska COMBI 108/LG – Junction box 76x76x51mm, polypropylene, RAL 7035
$34.29
$59.32
Material Polypropylene Material sealing gasket TPE Temp. range min -30 °C Temp. range max 100 °C Temperatures during install. -5 °C – 60 °C Protection class IP66 Glow wire test 750 °C Voltage 400 V Rated cross section 2,5 mm² Fixing 2 internal openings Ø cable diameter min 3 mm Ø cable diameter max 14 mm External dimensions LxWxH 76 x 76 x 51mm Using for cable gland Product Color RAL 7035 WISKA-Order no. 10060522 Type COMBI® 108 LG Packing unit 10 ETIM-Classification EC002600 Remarks: Fixing: By mounting clip or two internal openings outside of the sealing areaEquipment: 10 elastic self-sealing puncture-membranes for cable entry on the side and 2 in the bottom
